Add rich tuple decoder

[banteg]

What was wrong?

Rich objects can already be passed where tuples are expected as input, but there was no way to decode outputs as named objects even though their component names are usually available in the ABI.

Related to Issue #1267

How was it fixed?

There is a new decode option available when instantiating a contract which applies both to calls and contract caller. When enabled, all tuples/structs are decoded as namedtuples. They are kept compatible with the current API and should work everywhere a tuple is expected.

This works via web3._utils.abi.named_tree(abi, data) which decodes function inputs/outputs provided their ABIs. Internally it works with dicts as tuples have multiple limitations on how their fields can be named.

There are also two customized namedtuple factories:

• foldable_namedtuple(fields) which returns subclass of namedtuple which can be instantiated via a single argument, such that type(x)(x) == x. This is done to keep it compatible with _align_abi_input.
• Tuple(**kwargs) which works with literal representation, such that Tuple(x=1, y=2) returns Tuple(x=1, y=2). This is useful when copying the output so it can be loaded back easily.

This pull request also fixes tuple support for event parser.

Example

In [1]: from web3._utils.abi import named_tree, dict_to_namedtuple
In [2]: from tests.core.utilities.test_abi import TEST_FUNCTION_ABI
In [3]: from tests.core.utilities.test_abi import TEST_FUNCTION_ABI, GET_ABI_INPUTS_OUTPUT
In [4]: abi = TEST_FUNCTION_ABI['inputs']
In [5]: inputs = GET_ABI_INPUTS_OUTPUT[1]
In [6]: inputs
Out[6]: ((1, [2, 3, 4], [(5, 6), (7, 8), (9, 10)]), (11, 12), 13)
In [7]: decoded = named_tree(abi, inputs)
In [8]: decoded
Out[8]:
{'s': {'a': 1,
  'b': [2, 3, 4],
  'c': [{'x': 5, 'y': 6}, {'x': 7, 'y': 8}, {'x': 9, 'y': 10}]},
 't': {'x': 11, 'y': 12},
 'a': 13}
In [9]: dict_to_namedtuple(decoded)
Out[9]: Tuple(s=Tuple(a=1, b=[2, 3, 4], c=[Tuple(x=5, y=6), Tuple(x=7, y=8), Tuple(x=9, y=10)]), t=Tuple(x=11, y=12), a=13)

Cute Animal Picture

[banteg]

I just found out that decode_function_input was broken for tuple arguments. I fixed it as a part of this PR as the fix depends on the new functionality.

[kclowes]

Awesome @banteg! I still need to dig into this PR a little more in depth, but on a high level, I'd like to see some more testing around the named_data_tree (for example, what if a name is empty in the ABI?). Additionally, I think it makes sense to return a namedtuple instead of a dictionary since returning a dictionary will be a breaking change. Thanks for adding this!

[banteg]

Thanks for the feedback. I agree this needs more testing. I initially went with dict because this format is accepted as input kwargs, so I will need to dig into it a bit more to see if namedtuples would work as args, but that change makes sense. One function's output can be another function's input, so I think it's important to keep the parsed versions compatible.

[banteg]

Current progress with namedtuples:

# s = (a=1, b=[2, 3, 4], c=[(x=5, y=6), (x=7, y=8), (x=9, y=10)])
# t = (x=11, y=12)
# a = 13
inputs = [
    (1, [2, 3, 4], [(5, 6), (7, 8), (9, 10)]),
    (11, 12),
    13,
]
> result = [named_data_tree(*item) for item in zip(abi, inputs)]
> result
[(a=1, b=[2, 3, 4], c=[(x=5, y=6), (x=7, y=8), (x=9, y=10)]),
 (x=11, y=12),
 13]
> inputs == result
True

Now I need to figure out some quirks to make it work with _align_abi_input.

[banteg]

I've been playing with different ways to present an anon tuple and landed on (x=1, y=2). If only Python supported literal namedtuples.

This is how example from the first message now looks like:

> market = dydx.getMarket(1)
(token='0x89d24A6b4CcB1B6fAA2625fE562bDD9a23260359', totalPar=(borrow=1284671939554912048936288, supply=1999868739240631893521211), index=(borrow=1014323761632160906, supply=1008162740160717992, lastUpdate=1558020975), priceOracle='0x787F552BDC17332c98aA360748884513e3cB401a', interestSetter='0xad91a0ddf799176a0A87a32Dafe8F3dd28479918', marginPremium=(value=0), spreadPremium=(value=0), isClosing=False)
> market.totalPar
(borrow=1284671939554912048936288, supply=1999868739240631893521211)

These tuples now should work everywhere a tuple is expected. I've also added some tests, although not comprehensive.

The thing I dislike is that I can't just copy this representation and paste into another terminal. Maybe it can be alleviated with some clever factory that converts kwargs into tuples, but we won't have anonymous tuple representation then.

decode_function_input has moved to utilities as decode_transaction_data alongside encode_transaction_data. Now that it returns tuples, it has broke some tests, I'll take a further look tomorrow.

[banteg]

NB: Tests fail due to issues unrelated to this PR.

[kclowes]

Sweet, thanks! I reran the tests, so hopefully those will fix themselves. I'll take a look at the code tomorrow!

[banteg]

One idea to think about. If we define these two constructors, we can have copyable literal namedtuples which would require only one import to work. I think this feature is more important than concise anonymous representation. Also, should we call it Tuple or Struct?

def foldable_namedtuple(fields):
    class Tuple(namedtuple('Tuple', fields)):
        def __new__(self, args):
            return super().__new__(self, *args)

    return Tuple

def Tuple(**kwargs):
    keys, values = zip(*kwargs.items())
    return foldable_namedtuple(keys)(values)

For example:

> Tuple(a=1, b=[2, 3, 4], c=[Tuple(x=5, y=6), Tuple(x=7, y=8), Tuple(x=9, y=10)])
  Tuple(a=1, b=[2, 3, 4], c=[Tuple(x=5, y=6), Tuple(x=7, y=8), Tuple(x=9, y=10)])

[banteg]

One problem with namedtuple I found: ValueError: Field names cannot start with an underscore. I think leading underscores are uncommon in Struct definitions, but they are pretty common in function inputs.

[kclowes]

Unfortunately, since v5 is in beta now, we can't make any more breaking changes (until v6 which is a ways out). We'll need to keep decode_function_input returning the same dict.

Should we call it Tuple or Struct?

I like Tuple. I also wouldn't be opposed to something like DecodedABITuple or something more specific than just Tuple.

One problem with namedtuple I found: ValueError: Field names cannot start with an underscore

A few options that come to mind off the top of my head are:

• skip the conversion to a namedtuple, and just return the "unnamed" tuple, like it was doing before
• use the namedtuple rename=True option, and then people can access the underscored names by the index
• strip it like you're doing now

It seems to me like the easiest approach might be to just revert to returning a regular tuple for a couple reasons: 1) it feels unexpected to me to return a different name than the one that was provided in the ABI, and 2) what happens if we strip an underscore name which then becomes the same as a name that didn't originally have an underscore? Although, I can see where it would also be unexpected to have a regular tuple returned if you pass in the decode flag, so I don't have a strong opinion there. I think we'll just have to be clear in the documentation.

@pipermerriam I'd like to get your input here as well!

[banteg]

I think it would be enough to add this check after the stripping:

 def foldable_namedtuple(fields):
     fields = [field.lstrip('_') for field in fields]
+    if '' in fields or len(set(fields)) < len(fields):
+        return tuple

Example with fallback to tuple:

In [45]: foldable_namedtuple(['a', 'b'])([1, 2])
Out[45]: Tuple(a=1, b=2)

In [46]: foldable_namedtuple(['_a', '_b'])([1, 2])
Out[46]: Tuple(a=1, b=2)

In [47]: foldable_namedtuple(['_a', 'a'])([1, 2])
Out[47]: (1, 2)

In [48]: foldable_namedtuple(['_a', '_'])([1, 2])
Out[48]: (1, 2)

Example with rename=True option:

In [52]: foldable_namedtuple(['a', 'b'])([1, 2])
Out[52]: Tuple(a=1, b=2)

In [53]: foldable_namedtuple(['_a', '_b'])([1, 2])
Out[53]: Tuple(a=1, b=2)

In [54]: foldable_namedtuple(['_a', 'a'])([1, 2])
Out[54]: Tuple(a=1, _1=2)

In [55]: foldable_namedtuple(['_a', '_'])([1, 2])
Out[55]: Tuple(a=1, _1=2)

To me the latter example looks less predictable, so my vote is for reverting to a tuple on conflicting input.

As for decode_function_input, the previous version didn't work with tuples, I'd say let's keep the utility function for a future update and I'll update the contract method to return a dict with proper tuple decoding.

[banteg]

I've reverted the breaking change, now decode_function_input returns dict as before. It uses namedtuple decoder as an intermediate representation, so I've added an option as_dict=True to expose it.

[banteg]

Another issue with namedtuples: ValueError: Type names and field names cannot be a keyword: 'from'. Looks like my initial intuition about using dicts was correct. I'll try to play with inverted logic (tuple → dict → namedtuple) to see if it makes things less messy.

I also noticed that events completely lack tuple support, I'll try to address that too.

[banteg]

Vyper outputs scalars as tuple, so I addressed that to keep it compatible:

# before
In [2]: contract.caller().totalSupply()
Out[2]: Tuple(out=347980466501289403984)
# after
In [3]: uni_eth.caller().totalSupply()
Out[3]: 347980466501289403984

[pacrob]

closed by PR #2799. Thanks @banteg!
